400kva Diesel Generator Set Weather Proof VOLV Generator Set
| Place of Origin | CHINA |
|---|---|
| Brand Name | JINGTE |
| Model Number | FDV-320GF |
| Minimum Order Quantity | 1 set |
| Price | USD 48,600 per set |
| Packaging Details | neutral packing with wooden box, or as requested |
| Delivery Time | 25day |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 100 piece per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Power | 320kw/ 400KVA | Type | Mainly Power |
|---|---|---|---|
| Phase | 3phase, 50Hz/60hz | Noise | Lower |
| Voltage | 220v-600v | AppliCaterion | Industral |
| Highlight | 400kva Diesel Generator Set,Weather Proof VOLV Generator Set,400kva VOLV Generator Set |
||
You can tick the products you need and communicate with us in the message board.
| Generator | open type | Volvo | |
|---|---|---|---|
| NEW Generating set | 50hz/60hz | 3phase, 4wire | |
| Diesel Genrator | main Or Standby power | auto start |
Product Description
VOLV 400kva Generating Set Weather Proof Diesel Generator Set
1. Professional Diesel generator factory
|
Genset Model
|
FDV-320GF
|
||
|
Prime Power/Standby power
|
5KW to 2000KW
|
||
|
Frequency/Speed
|
50hz/1500 rpm
|
60hz/1800rpm
|
|
|
Voltage
|
220v-600v
|
110v-480v
|
|
|
Phase
|
Three phase
|
Single phase
|
|
|
Fuel type
|
Diesel
|
Gas
|
|
2. Diesel Generator Set Advantage
*50Hz@1500rpm or 60Hz@1800rpm all are available
*AVR delivers non fluctuating power
*Panel type digital control panel
*12 Volt / 24 Volt electric starter ensures easy starting
*Low oil pressure shut down system
*Low fuel cut out protection
*Low water cut out engine protection
*Enclosed structure ensures quieter operation
*Alternator (Dynamo) excitation mode brushless self excitation
*Three-phase output meets differing requirements
*Four Cylinder, four stroke, water cooled diesel engine
*8 hours running @ full load on a single tank of fuel
*Dual access doors for easy maintenance
*Optional automatic or manual transfer switches available
*ATS ( auto transfer switch for city power and generator power ) / AMF (auto mains failure) /parallel running for option
*Weatherproof and soundproof, enclosure high grade steel protected by powder coat painting and incorporate internally mounted exhaust silencers
*Noise Level (65-70dBA @ 7m)
All ratings are at sea level!!!
3. After-sales Service
*1 year or 1500 running hours subject to the earlier one.
4. Terms of Payment
T/T ,Western Union,Cash
5. Main data
| 400 KVA DIESEL GENERATOR | |
| Generator model: RMV-400 | Steady state voltage regulation(%): ≤±0.5 |
| Output powder:400kva | Voltage fluctuation rate(%):≤0.5 |
| Powder factor: COSΦ=0.8 in three phase | Transient voltage regulation(%):-15~+20 |
| Output voltage: 110/220v/230v/400v/415v | Voltage steady state time(s):≤0.5 |
| Output current:665Amp | Steady state frequency adjustment rate(%):0~5 adjustable |
| Rated frequency:60Hz/50Hz | Frequency fluctuation rate(%):≤0.5 |
| Rated speed: 1800rpm/1500rpm | Transient frequency modulation rate(%):≤±10 |
| Fuel brand: ( standard) 0# light diesel oil( room temperature) | Frequency recovery time(s): :≤5 |
| Fuel consumption:199g/kw.h | |
| Gross size | 3520*1160*1960mm |
| Gross weight | 3110kg |
| Diesel Engine Technical Parameters | |
| Brand/origin: With VOLV Engine | Cooling mode: closed cooling water circulation |
| Engine type: TTAD1641GE | Oil supply: direct injection |
| Rated power:400kw/500kva | Speed adjustment: Electronic |
| Standby power:410kw/512Kva | |
| Qty of cylinders/cylinder structure: 6 cylinder on line | Air inlet: turbo Charged |
| Bore by stroke: 144*165mm | Overload capacity: 110% |
| Engine oil capacity: 35L | Discharge :16.12L |
| Compression ratio: 18:1 | Rated speed: 1800rpm/1500rpm |
| Startup mode: DC 24V electric start | |
| Brushless synchronous Alternator | |
| Brand: RAYMING | Insulation class: H |
| Model:RMV354D | Connection mode: three phase four wire, Y type |
| Rated powder:400kw/500kva | Adjust way: AVR( automatic voltage regulator) |
| Output frequency: 60Hz/50Hz | Output factor: COS Φ=0.8 |
| Rated speed: | 1800rpm/1500rpm |
| Battery | 2*105A |
| Control panel | |
| Model | Smartgen/Deepsea/ComAp |
