Nature Gas 1500kw Diesel Generator Set Mitsubishi Open Type
| Place of Origin | CHINA |
|---|---|
| Brand Name | JINGTE |
| Model Number | FDC-1500GF |
| Minimum Order Quantity | 1 set |
| Price | USD 228,600 per set |
| Packaging Details | neutral packing with wooden box, or as requested |
| Delivery Time | 25day |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 100 piece per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Power | 1500kw/ 1875KVA | Type | Gas Primary Using Engine |
|---|---|---|---|
| Phase | 3phase, 4wire, High Efficency | Power(KW) | 1500 |
| Frequency(Hz) | 50 | AppliCaterion | Air-cooling And Water Cooling |
| High Light | 1500kw Diesel Generator Set,Mitsubishi Open Generator Set,Mitsubishi Diesel Generator Set |
||
You can tick the products you need and communicate with us in the message board.
| Generator | Weather-proof Canopy | jichai | |
|---|---|---|---|
| NEW Generating set | 1500kw | 3phase, 4wire | |
| Gas generator | power station | water cooling |
Product Description
Nature Gas 1500kw Generating Station Mitsubishi Open Type Diesel Generator Set
1. Professional Gas generator supplier
2. General features:
- Engine:Mitsubishi S16R-PTA2-C
- Alternator: Leroy Somer LSA53.2VL6
- Digital Controller:Smartgen HGM6120
- Equipped with 45℃ Radiator;
- Equipped with 24V DC Start motor;
- Equipped with 3200A Aisikai Brand Circuit Breaker;
- Every generator set is subjected to a comprehensive test program which includes 50% load, 75% load,100% load, 110% load and the checking and proving of all control and safety shut-down functions
| 1. Main Technical Data of Generator | ||
| Genset Model | ML1500GF | |
| Power(KW) | 1500 | |
| Current(A) | 100 | |
| Dimension(L×W×H) | 5460*2200*2480mm | |
| Weight | 14560kg | |
| Rated Voltage Output(V) | 10500V | |
| Frequency(Hz) | 50 | |
| Rated Speed(rpm) | 1500 | |
| Rated Power Factor | 0.8 | |
| Excitation Method | Brush less & Self-excited | |
| Start Method | DC24V Electrical | |
| Cooling Method | Closed Fan & Water Cooling | |
| 2. Main Performance IndiCatererors of Genset | ||
| Frequency Drop(%) | ≤5 | |
| Steady-state Frequency Band(%) | ≤1.5 | |
|
Transient
Frequency Deviation |
100%Sudden Power Reduction(%) | ≤12 |
| Sudden Power Rise(%) | ≤-10 | |
| Frequency Recovery Time(S) | ≤3 | |
| Relative Frequency Tolerance Band(%) | 2 | |
| Steady-state Voltage Deviation(%) | ≤±2.5 | |
| Voltage Adjust Range | ≤±5 | |
|
Transient
Voltage
Deviation |
100%Sudden Power Reduction(%) | ≤+20 |
| Sudden Power Rise (%) | ≤-20 | |
| Voltage Recovery Time(S) | ≤6 | |
3. Engine date
| Engine Model | Mitsubishi S16R-PTA2-C |
| Rated Power(KW) | 1600 |
| Rated Speed(rpm) | 1500 |
| Type | Water Cooling,V type,Four Stroke |
| No. Of cylinder | 16.V |
| Compression Ratio | 13.5: 1 |
| Bore & Stroke | 170*180 |
| Oil Grade | CF15W/40 |
| Fuel Consumption 100% Load | 388L/h |
| Displacement | 65.37L |
