200kw Perkins Diesel Generator Set 3 Phase 50Hz Silent
| Place of Origin | CHINA |
|---|---|
| Brand Name | JINGTE |
| Model Number | FDP-200GF |
| Minimum Order Quantity | 1 set |
| Price | USD 3,600 per set |
| Packaging Details | neutral packing with wooden box, or as requested |
| Delivery Time | 25day |
| Payment Terms | L/C,T/T,Western Union |
| Supply Ability | 100 piece per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Power | 200kw/ 250KVA | Type | Standby Using Iwth ATS |
|---|---|---|---|
| Phase | 3phase， 4wire, 50Hz | AppliCaterion | Wilderness |
| Product Name | Diesel Generator Set | Rated Frequency | 50/60 Hz |
| Brand | Top Brand Of Engine And Alternator | Shipment | By Sea |
| Highlight | ISO 200 Kw Perkins Generator,50Hz Silent Generator Set,200 Kw Perkins Generator 50Hz |
||
You can tick the products you need and communicate with us in the message board.
| Generator | Soundproof | Perkins | |
|---|---|---|---|
| NEW Generating set | 50hz | 3phase, 4wire | |
| Diesel Genrator | Supply power | ATS Starting |
Product Description
ISO 200 Kw Perkins Generator 4wire 50Hz Silent Generator Set
| Power | 200kw/ 250KVA |
|---|---|
| Type | Standby using with ATS |
| Phase | 3 phase, 4 wire, 50Hz |
| Application | Wilderness |
| Product Name | Diesel Generator Set |
| Rated Frequency | 50/60 Hz |
| Brand | Top brand of engine and alternator |
| Shipment | By sea |
Full New Perkins 200kw Genset Soundproof Diesel Generator Set
Professional OEM Diesel Generator Factory
- Diesel Generator: Open type or silent type (soundproof type)
- Generator Diesel Engine: C engine, UK Perkin, Deutz, Steyr, etc.
- Generator with alternator: Stamford, Leroy Somer, Marathon, etc.
- Diesel Generator Rated output: 5kVA - 2000kVA
- Rated frequency: 50/60 Hz
- Rated voltage: 230/400, 220/380, according to customers
- Power factor: 0.8(lag)
- Super Silent type: Noise level at 7m ≤ 65DB
- Excitation Mode: (Brushless) Self-excitation and constant voltage (AVR)
- Starting system: Electric start 12V/24V
- Protection System: High water temperature protection, Engine oil alarm, Over load Protection
- Overfrequency protection, Emergency stop
- Control System: Digital Control Panel; Meter Panel
Diesel Generator Set Advantages
- 50Hz@1500rpm or 60Hz@1800rpm all are available
- AVR delivers non fluctuating power
- Panel type digital control panel
- 12 Volt / 24 Volt electric starter ensures easy starting
- Low oil pressure shut down system
- Low fuel cut out protection
- Low water cut out engine protection
- Enclosed structure ensures quieter operation
- Alternator (Dynamo) excitation mode brushless self excitation
- Three-phase output meets differing requirements
- Four Cylinder, four stroke, water cooled diesel engine
- 8 hours running @ full load on a single tank of fuel
- Dual access doors for easy maintenance
- Optional automatic or manual transfer switches available
- ATS (auto transfer switch for city power and generator power) / AMF (auto mains failure) / parallel running for option
- Weatherproof and soundproof, enclosure high grade steel protected by powder coat painting and incorporate internally mounted exhaust silencers
- Noise Level (65-70dBA @ 7m)
All ratings are at sea level!
After-sales Service
1 year or 1800 running hours subject to the earlier one.
Our Diesel Generator Set Production Range
Engine (Motor) Options
- C engine (USA) 20kVA - 2000kVA
- Deutz (Germany) 20kVA - 150kVA
- Perkin (UK) 8kVA - 2000kVA
- Chinese 8kVA - 150kVA
- Yuchai Engine
Canopy Options
- Silent type (75-80 dB(A) at 7 meters)
- Super Silent type (65-70 dB(A) at 7 meters)
- Open type
- Trailer type (mobile)
- Container Type
- Parallel System
Terms of Payment
T/T, Western Union, Cash
