Low Protraction Wedge V Belt Industrial Fan Engine PVC Rubber Timing Classical

Place of Origin CHINA
Brand Name JINGTE
Model Number D914
Minimum Order Quantity 1pcs
Price USD 5 per piece
Packaging Details neutral packing with carton box
Delivery Time 25 day
Payment Terms L/C, T/T, Western Union
Supply Ability 500 piece

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Material PVC Rubber AppliCaterion Engineering Machines
Type Timing Classical Color Black / Grey / Red
Usage Connecting Appearance Grooved And Flat
Brand Duetz Engine Belt Price Competitive
High Light

Low Protraction Wedge V Belt

,

PVC Rubber Wedge V Belt

You can tick the products you need and communicate with us in the message board.
Timing v- belt Deutz engine OEM produced
fan belt aluminum made ODM TYPE
Wrapped Wedge belt seal system ISO Certificate
Leave a Message
Timing v- belt Deutz engine OEM produced
Product Description

Industrial Fan Engine PVC Rubber Timing Classical Wrapped Wedge V Belt Diesel Engine Parts



Features

Wrapped V-belts feature high strength, low protraction, small matching tolerance and

a fatigue endurance limit of over ten million times. Suitableall industrial light duty appliCatererions,

usually using fractional horsepower motors, plant protection machinery such as lawn mowever,

wool conveyror, carton packing machine andother fields requiring strict enviromental protection.





Type Top width Pitch width Height Angel Length conversion Length
Range inch
Length
Range mm
Z 10 8.5 6 40º Li=Ld-22 13"-120" 330-3000
A 13 11.0 8 Li=Ld-30 14"-394" 356-10000
AB 15 12.5 9 Li=Ld-35 47"-394" 1194-10000
B 17 14.0 11 Li=Ld-40 19"-600" 483-15000
BC 20 17.0 12.5 Li=Ld-48 47"-394" 1194-10008
C 22 19.0 14 Li=Ld-58 29"-600" 737-15240
CD 25 21.0 16 Li=Ld-61 47"-394" 1194-10008
D 32 27.0 19 Li=Ld-75 80"-600" 2032-15240
E 38 32.0 23 Li=Ld-80 118"-600" 2997-15240
F 50 42.5 30 Li=Ld-120 177"-600" 4500-15240



Structure

1. Cover fabric, made of cotton fabric and polyester fabric, to protect the inner parts of the belts

and provide strong abrasion on the pulley groove.

2. Tension member, made of polyester and Kevlar cord, to provide the transmission power.

3. Top compression rubber, Adhesive rubber, Bottom compression rubber, made of NR, CR, SBR,

to maintain the belt shape and protect tension meber adhesion.



Deliver time: Normally ready goods in stock   Port: Tianjin, CN



Payment term: 30%TT in advance, 70% before shipment
