Hand-Held Mini Drum Roller FM-600S with Auto Vibration
| Place of Origin | CHINA |
|---|---|
| Brand Name | JINGTE |
| Model Number | FM-600S |
| Minimum Order Quantity | 1 set |
| Price | USD 2,000--100,000 per set |
| Packaging Details | neutral packing with wooden box, or as requested |
| Delivery Time | 15day |
| Payment Terms | L/C,T/T,Western Union |
| Supply Ability | 200 piece per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | Cast Iron And Steel | Drive | Hand Hold |
|---|---|---|---|
| Type | Single Drums | Vibration | Full Automative |
| Usage | Compact For Narrow Area | Quality | ISO9001 CertifiCatere |
| Guarantee | 6 Month | Delivery | 15 Days |
| Highlight | Cast Iron Single Drum Vibrating Roller,Electric Starting Single Drum Vibrating Roller,4 Cycle Gasoline Single Drum Roller |
||
You can tick the products you need and communicate with us in the message board.
| single roller | cast iron,steel | Changchai | |
|---|---|---|---|
| vibration | single drum moving | Diesel Changchai | |
| Hand-hold roller | domestic | Changchai |
Product Description
Cast Iron Hand Held Mini Drum Roller Electric Starting Single Drum Vibrating Roller
Product Specifications
| Attribute | Value |
|---|---|
| Material | Cast iron and steel |
| Drive | Hand hold |
| Type | Single drums |
| Vibration | Full automatic |
| Usage | Compact for narrow area |
| Quality | ISO9001 certified |
| Guarantee | 6 months |
| Delivery | 15 days |
Single Drum Roller FM-600S, Hand-Held Auto-vibration Mini Drum Roller
Roller: Mini roller, single drum roller, hand-hold roller
Material: Casting iron, steel structure
Technical Specifications
| Model | FM-600D | FM-600S |
|---|---|---|
| Weight | 550KG | 330KG |
| Water tank | 35L | 15L |
| Oil tank | 6L | 3.6L |
| Walking speed | 0-4km/h | 0-4km/h |
| Starting way | Electric starting | Electric starting |
| Driving mode | Hydraulic drive | Hydraulic drive |
| Walking mode | Forward & Back | Forward & Back |
| Wheel size | 600*426mm | 600*426mm |
| Vibrating clutch method | Automatic | Automatic |
| Centrifugal force | 25kn | 15kn |
| Vibration frequency | 70hz | 70hz |
| Grade ability | 30% | 25% |
| Package size | 1350*940*1220mm | 1000*1000*1200mm |
| Engine | Air-cooled 4-cycle gasoline/diesel | Air-cooled 4-cycle gasoline/diesel |
| Engine type | 178FA/HONDA GX270 | 170FA/HONDA GX160 |
| Fuel consumption | 280g/KWH 313g/KWH | 280g/KWH 313g/KW |
Applicable Areas
Special for narrow areas in engineering industry, construction, marine industry etc.
Key Features
- Hydraulic parts with high capacity are completely imported, ensuring machine reliability
- Light duty and modular design for convenient operation, transportation and storage
- Adjustable impact effect, with customization available according to customer requirements
- Easy operation for forwarding, backward and vibrating in place with stepless speed adjustment
- Adjustable handle height suitable for operators of different heights for comfortable operation
- Excellent slope climbing capacity suitable for various working areas
- Plastic water tank with large volume and scrapers ensure clean steel roller surface
Packaging & Delivery
Package: Wooden package + pallet
Delivery time: Normally ready goods in stock
Port: Tianjin, CN
Payment terms: A: 100% LC at sight / B: 30% TT in advance, 70% against copy of B/L
